Ceres-170

17" Digital Signage Station

Download the spec. sheet.




Features



- Continuous looping video,
  photo or slide show
- Daily schedule on/off control, 4 time zones
- Interactive Media Display (IMD) features
- Available in wall mount and panel mount
- Motion sensor (optional)



Additional Images:






Specifications




General



Screen Type:



17” TFT LCD



Screen Resolution:



1280 x 1024



Brightness:



400nits



Lamp Life Time:

  40000hr (Brightness of lamp becomes 50% of the initial brightness)


Contrast Ratio:

  1:500


Viewing Angle:

  (H) 120 degrees, (V) 120 degrees


Support media:

  CF, SD


Video Resolution:



Native decoding - 720x480
Output - 640x480



JPEG resolution:



Native decoding - 5120x3840(max.)
Output - 640x480



Support Playback:



JPEG, Motion JPEG, MP3, WMA,
MPEG1/2/4



Auto Start mode:

  Auto start when power is turn on
Auto Slide show JPEG with Background MP3 music


Playback mode:

  Continuous Loop mode
IMD mode


Timer schedule:

  Daily schedule on/off control, 4 time zones


Power input:

  100~240VAC


Speakers:

  2 Watts x 2Ch Ext. Jack
