- Support HD video (1080p, 1080i, 720p)
- Support larger LCD screen, VGA 1920 x 1200, YPbPr 1080P, 1080i
- Multi-zone layouts flexible for combining video, text, and images (7 max)
- H/W Mixer 1366x768 (16:9)
- Edit Playlist from http web-interface
- Update content through USB
Specification
Software
OS
Embedded Linux
Support Media
HD, DVD-Video, WMV9, JPEG
Video Specification
- MPEG-1 [.mpg], MPEG-2 @(720p/1080i) [.mpg, .vob]
- MPEG-4 ASP @ L5 (729p) [.mp4, .avi]
- Windows Media Video 9 MP/ML (720p) (.wmv)
Photo Specification
- JPEG
Playback Mode
Local stored media & playlist playback
Playlist Editing
SignageNow Server
Web application no software installation needed. Upload content, design template, setup playlist & schedule
Content Updating
USB Drive
Hardware
CPU
RISC 200MHz
Memory
VGA:1280 x 720, 640 x 480;
YPbPr: 1080i, 720P, 480P
Flash
16MB
Mixer
1366 x 768
Storage
4GB SSD (Solid State Disk)
Display Output
VGA - 1920 x 1200, 1920 x 1080, 1280 x 1024, 1024 x 768
YPbPr - 1080P, 1080i, 720P
