Specifications |
|
|
| |
|
|
General |
| |
|
|
CPU: |
|
Intel Celeron M 600MHz processor. |
| |
|
|
Chipset: |
|
Intel 82852GM & ICH4 |
| |
|
|
Memory: |
|
1 x DDR200/266 SDRAM socket up to 1 GB |
| |
|
|
Display: |
|
Intel 852GM built-in Intel Extreme Technology. 24-bit LVDS interface up to 1400 x 1050 of resolution. Onboard 5-pin LCD inverter connector. |
| |
|
|
IDE: |
|
2 x Ultra ATA/100 IDE channel up to 4 IDE devices. 1 x 44-pin IDE connectors. |
| |
|
|
Ethernet |
|
1 x Intel 82562ET 10/100Mbps PHY |
| |
|
|
SSD:: |
|
IDE1 44-pin supports DiskOnModule with + 5V power supply.
Onboard Compact Flash Type-II socket |
| |
|
|
I/O: |
|
1 x RS-232 port, 1x Parallel, 2x USB2.0 port, 1x slim FDD. |
| |
|
|
Audio: |
|
Intel ICH4 integrated with Realtek ALC201A AC97 Codec. |
| |
|
|
Expansion Slot: |
|
1 x Mini-PCI slot
Extended PCI interface through optional riser card up to 2 devices |
| |
|
|
Power Requirement: |
|
+12V DC |
| |
|
|
| |
|
|
| |
|
|
