Specifications |
|
|
| |
|
|
General |
| |
|
|
CPU: |
|
Intel® LGA775 Pentium 4 up to 800 MHz FSB |
| |
|
|
Chipset: |
|
Intel 915GV and ICH6R |
| |
|
|
Memory: |
|
Dual channel DDR2 533/400 MHz SDRAM socket up to 4 GB |
| |
|
|
Display: |
|
Intel 915GV integrated GMA 900
DVI interface for digital display devices Dual display spported
Video memory up to 224MB shared with system memory |
| |
|
|
IDE: |
|
1 x Ultra ATA/100 IDE channel up to 2 IDE devices |
| |
|
|
Serial ATA: |
|
4 x Serial ATA Interface with 150MB/s transfer rate |
| |
|
|
Ethernet: |
|
1x Marvell E8053 PCI Express Gigabit Ethernet & 1 x Intel® 82562EZ PHY 10/100 Mbps LAN |
| |
|
|
SSD: |
|
Onboard Compact Flash Type-II socket |
| |
|
|
I/O: |
|
1 x RS232/422/485 serial port, 1 x parallel port, 1 x FDD, 4 x USB 2.0 ports, 1 x IrDA, 8-bit Digital I/O interface |
| |
|
|
Audio: |
|
Intel ICH6R integrated with Realtek ALC201A AC97Codec |
| |
|
|
Watchdog: |
|
256-level generates NMI or system reset programmable watchdog timer |
| |
|
|
Power Requirement: |
|
+5V & +12V DC input from PICMG slot and ATX12V connector |
| |
|
|
| |
|
|
